Concrete Mixer Lorry Reversing Camera Monitor System For Cement Mixer ,Mixer Truck,Concrete Mixer Truck,Cament Concrete Mixer Lorry ,Mixer Lorry
7" Digital Screen TFT LCD Monitor Automatically Adjust Brightness to Display and Button by According Environment, DC14+87V(Td400mS) 5pulses Load Dump, 400cd/m2 Brightness, OSD Menu Separately Set Each Camera Mirror/Normal image,Trigger Priority of Camera image Display,Reversing Image Delay Time 0-30"
Mini Aluminum Shell Camera IP69K Waterproof and 10G Vibrationfo, IR LED's for Picture Support in the Dark
System Free Operating Voltage DC8~32V

Specification

7"Digital Screen TFT LCD Monitor

7 inches Digital Screen TFT LCD Color Monitor(Model:SP-727N)

7"Digital Screen TFT LCD Color Monitor with Removable Sun Visor

Accepts up to 2 Cameras Video Inputs:1.0Vp-p75Ω

OSD MENU Separately Set Each Camera Trigger Priority

OSD MENU Separately Set Each Camera Reversing Image Delay Time 0-30s

OSD MENU Separately Set Each Camera Mirror/Normal image

Manual and Automatic Switch Display Mode

Color System:PAL/NTSC (AUTO)

Display Resolution: 2400(H) X 480(V) dot

Support Three Camera Video Inputs:1.0Vp-p75Ω

Wide view angle(CR>10):(up/ down): 50/70 (left/right): 70/70

Brightness (cd/m2): 400( Automatically Adjust Environment by According)

Contrast ratio: 500:1

Back-light:Single LED 400cd/m2 Brightness

Operating temperature: -20ºC to +70ºC

Storage temperature: -30ºC to +80ºC

Load Dump:DC14+87V(Td400mS) 5pulses

Free Operating Voltage DC11-32V

External dimensions::L*W*T(180X118X38)mm(without mounting)

Aluminum Shell Waterproof IR Color CMD Camera(MODEL:DF-4103*2)

Image Type:1/3 Inch Color CCD

Horizontal Resolution:600TV Lines

Effective pixel:PAL: 920L×582V NTSC: 940L×494V

Usable Illumination : 0Lux ( Built in IR LED's for Picture Support in the Dark)

Free viewing angle: 130°

Waterproof: IP69k

Shockproof: 10G

Video Output:1.0Vp-p75Ω

Power supply:DC12V (from Reversing Monitor)

Dimensions: 69(W) x 43(H) x 38(D) mm (without mounting)

Product Accessories

U- Support Bracket,Angle Adjustment Screw,Removable Sun Visor,Electrical Connecting Cable,15m cable*2, Auto cigarette lighter,User's Manual
