Security Quad Monitor Rear Vision Camera System for Heavy Equipment
Product Description
Digital Security Wired Quad Touch Screen Backup System
Quad Monitor Rear Vision Camera System Eliminate Blind Spots on Bus, Farm Tractor, Agricultural Machinery,Port Crane,Rail & Tram,mobile vehicle
monitor is able to Show 1,2,3,4 Views at one Time, OSD MENU Separately Set Each Camera image Mirror/Normal,Priority and Delay,ON/OFF,400cd/m2 Brightness, Load Dump DC14+87V(Td400mS) 5pulses
Aluminum Shell Side Top Camera 700TV Lines IP69K Waterproof and 10G Vibration, Ultra Bright Wavelength 850nm IR LEDs for Night Vision, Always Positioned Correctly No Matter What The Location
System Free Operating Voltage DC11~32V
Specification
Contact us if you need more details on Wired Backup System. We are ready to answer your questions on packaging, logistics, certification or any other aspects about Digital Quad System、Security Backup System. If these products fail to match your need, please contact us and we would like to provide relevant information.
Quad Monitor Rear Vision Camera System Eliminate Blind Spots on Bus, Farm Tractor, Agricultural Machinery,Port Crane,Rail & Tram,mobile vehicle
monitor is able to Show 1,2,3,4 Views at one Time, OSD MENU Separately Set Each Camera image Mirror/Normal,Priority and Delay,ON/OFF,400cd/m2 Brightness, Load Dump DC14+87V(Td400mS) 5pulses
Aluminum Shell Side Top Camera 700TV Lines IP69K Waterproof and 10G Vibration, Ultra Bright Wavelength 850nm IR LEDs for Night Vision, Always Positioned Correctly No Matter What The Location
System Free Operating Voltage DC11~32V
Specification
| 7 inches Quad Monitor(Model:SP-767) |
| Digital Screen TFT LCD Quad Monitor with Removable Sun Visor |
| Single View/Split View/Three View/Quad image View Selectable Totally 9 different view modes. Each Image full displayed when it is triggere |
| OSD MENU Separately Set Each Camera Trigger Priority Rear View Camera Visor System |
| OSD MENU Separately Set Each Camera Reversing Image Delay Time 0-30s Drive Monitor |
| OSD MENU Separately Set Each Camera Mirror/Normal image Rear View Camera Visor System |
| OSD MENU Separately Set Each Image ON/OFF |
| 1 Cable Solution System Make It Easy For Users To Install and Use The Device In Any Places |
| Color System:PAL/NTSC (AUTO) Rear View Camera Visor System |
| Display Resolution: 2400(H) X 480(V) dot |
| Support Four Camera Video Inputs:1.0Vp-p75Ω |
| Wide view angle(CR:10):(up/ down): 45/65 (left/right): 65/65 |
| Brightness (cd/m2): 400 |
| Contrast ratio: 500:1 |
| Back-light:Single LED |
| Operating temperature: -20°C to +70°C Rear View Camera Visor System |
| Storage temperature: -30°C to +80°C Rear View Camera Visor System |
| Load Dump: DC14+87V(Td400mS) 5pulses Rear View Camera Visor System |
| Free Operating Voltage DC11-32V Rear View Camera Visor System |
| External dimensions:L*W*T(185X124X48)mm(without mounting) |
| Weight Approx: 468g |
| Aluminum Shell Waterproof IR Side CCD Camera(MODEL:DF-8059*4) |
| Image Type: 1/3 inch Color CCD |
| Resolution:700TV Lines |
| Effective pixel:NTSC:976(H)×494(V) PAL:976(H)x582(V) |
| Usable Illumination : 0Lux( Built in 10pcs IR LED's for Picture Support in the Dark) |
| Free viewing angle: 130° |
| Waterproof: IP69K |
| Shockproof: 10G |
| Video Output:1.0Vp-p75Ω |
| Power supply:DC12V (from Reversing Monitor) |
| Dimensions: 74(W) x 49(H) x 57(D) mm |
| Product Accessories |
| U- Support Bracket,Angle Adjustment Screw,Removable Sun Visor,Electrical Connecting Cable,15m cable*4, Auto cigarette lighter,User's Manual |
Contact us if you need more details on Wired Backup System. We are ready to answer your questions on packaging, logistics, certification or any other aspects about Digital Quad System、Security Backup System. If these products fail to match your need, please contact us and we would like to provide relevant information.
