Security Digital Rear View System for Bus, Truck and Tractor

Product Description

Security Digital Rear View System For Bus,Truck and Tractor
Rear View System for Bus,Truck,HVG,Port Crane,Airport vehicle,Farm Tractor,Heavy Equipment,Municipal Vehicle
9" Digital Screen TFT LCD Monitor Free Operating Voltage DC11-32V, DC14+87V(Td400mS) 5pulses Load Dump,400cd/m2 Brightness
Application USA Techwell Automotive Digital Video Processor,OSD Menu Separately Set Each Camera Mirror/Normal image,Trigger Priority of image,Reversing Image Delay Time 0-30"
Dual Aluminum Shell Side Camera Always Positioned Correctly, No Matter What The Location,IP69K Waterproof and 10G Vibration, 10pcsIR LED's for Picture Support in the Dark

Specification
TFT LCD Color Monitor(Model:SP-960)
9"Digital Screen TFT LCD Color Monitor with Sun Visor
Accepts up to 2 Cameras Video Inputs:1.0Vp-p75Ω
OSD MENU Separately Set Each Camera Trigger Priority
OSD MENU Separately Set Each Camera Reversing Image Delay Time 0-30s
OSD MENU Separately Set Each Camera Mirror/Normal image
Manual and Automatic Switch Display Mode
Color System:PAL/NTSC (AUTO)
Display Resolution: 800RGB(H) X 480(V) dot
Accepts up to 2 Cameras Video Inputs:1.0Vp-p75Ω
Wide view angle(CR:10):(up/ down): 50/70 (left/right): 70/70
Brightness (cd/m2): 400( Automatically Adjust Environment by According)
Contrast ratio: 500:1
Back-light:Single LED
Operating temperature: -20ºC to +70ºC
Storage temperature: -30ºC to +80ºC
Load Dump:DC14+87V(Td400mS) 5pulses
Free Operating Voltage DC11-32V
External dimensions::(L x W x T) (234 x158 x 81mm) with mounting Sun Visor
Weight Approx: 479g
Aluminum Shell Side Waterproof IR Color Camera(MODEL:DF-8053*2)
Image Type: 1/3 inch Color CCD
Horizontal Resolution:700TV Lines
Effective pixel:NTSC:976(H)×494(V) PAL:976(H)x582(V)
Usable Illumination : 0Lux ( Built in 10pcs IR LED's for Picture Support in the Dark)
Free viewing angle: 130°
Waterproof: IP69k
Shockproof: 10G
Video Output:1.0Vp-p75Ω
Power supply:DC12V (from Reversing Monitor)
Dimensions: 55(L) x 63(W) x 74(H)mm
Product Accessories
U- Support Bracket,Angle Adjustment Screw,Electrical Connecting Cable,15m cable*2, Auto cigarette lighter,User's Manual
Security Digital Rear View System for Bus, Truck and Tractor

Security Digital Rear View System for Bus, Truck and Tractor
Security Digital Rear View System for Bus, Truck and Tractor
Security Digital Rear View System for Bus, Truck and TractorSecurity Digital Rear View System for Bus, Truck and Tractor
Security Digital Rear View System for Bus, Truck and TractorSecurity Digital Rear View System for Bus, Truck and Tractor






Contact us if you need more details on Rear View System. We are ready to answer your questions on packaging, logistics, certification or any other aspects about Security Rear View System、Digital Rear View System. If these products fail to match your need, please contact us and we would like to provide relevant information.

Product Categories : 1080P / 720P Backup Camera System
