7′′ Digital Wireless DVR Quad Monitor Camera System
Product Description
Digital Wireless DVR Quad Monitor Camera system
Digital wireless video camera surveillance system four pictures used in the container trailers, tank trailers, cranes, and other construction vehicles, without cables through the routing application, you can monitor four screen images and video playback screen.
7 "digital screen TFT LCD display, built-in DVR, 2.4GHz digital wireless receiver, four screen / single-screen display, drawing the line of the menu, and individually set Front / Left / Right / Back frame around the mirror, upside down, flipped up and down, single cycle through the images individually set time 5-45s, Back channel individually set reversing ruler.
DC14~+87V(Td400mS) 5pulses Load Dump,400cd/m2 Brightnes
2.4GHz Digital Wireless Camera Aluminum Camera IP69K
Contact us if you need more details on 7′′ Digital Wireless Monitor Camera System. We are ready to answer your questions on packaging, logistics, certification or any other aspects about Car Rear View System、Backup Camera System. If these products fail to match your need, please contact us and we would like to provide relevant information.
Digital wireless video camera surveillance system four pictures used in the container trailers, tank trailers, cranes, and other construction vehicles, without cables through the routing application, you can monitor four screen images and video playback screen.
7 "digital screen TFT LCD display, built-in DVR, 2.4GHz digital wireless receiver, four screen / single-screen display, drawing the line of the menu, and individually set Front / Left / Right / Back frame around the mirror, upside down, flipped up and down, single cycle through the images individually set time 5-45s, Back channel individually set reversing ruler.
DC14~+87V(Td400mS) 5pulses Load Dump,400cd/m2 Brightnes
2.4GHz Digital Wireless Camera Aluminum Camera IP69K
| Digital Wireless Receive Monitor(Model:SP-766H4DVR) |
| 7" Digital Screen TFT LCD Monitor with Removable Sun Visor |
| Built-in 2.4G digital wireless receiver module, supports single screen / quad screen display |
| Built-in DVR recording function, maximum support 64G SD card |
| Operation Frequency:2400 ~ 2483.5MHz |
| Receiving Sensitivity:≤-86dBm(1MHZ QPSK MD300RE) |
| Overlapping Hopping Channel:80 |
| Color System:PAL/NTSC |
| Display Resolution: 800RGB(H) X 480(V) dot |
| Wide view angle(CR>10):(up/ down): 50/70 (left/right): 70/70 |
| Brightness (cd/m2): 450 |
| Contrast ratio: 500:1 |
| Operating temperature: -20ºC to +70ºC |
| Storage temperature: -30ºC to +80ºC |
| Free Operating Voltage: DC8~32V |
| External dimensions:(L x W x T) (199 x 128 x 28mm) without mounting Sun Visor |
| Weight Approx: 400g |
| Digital Wireless Waterproof IR Camera(MODEL:DF-8275H-SFS-CUT*4) |
| Image Type: 1/3 inch Color CMOS |
| Built in 2.4GHz Digital wireless transmitter |
| Transmission Power:18dBm with Power control |
| Line of Sight Range:≤100M |
| Horizontal Resolution:600TV Lines |
| Effective pixel:976(H)X496(V) |
| Usable Illumination : 0Lux ( Built in 18pcs IR LED's for Picture Support in the Dark) |
| Free viewing angle: 120° |
| Waterproof: IP69K |
| Shockproof: 10G |
| Free Operating Voltage: DC8-32 Volts |
| Dimensions: 106(W) x 75(H) x 70.4(D) mm (without mounting) |
| Weight : 450g |
| Accessorie |
| U- Support Bracket,Angle Adjustment Screw*2,Removable Sun Visor*1,Electrical Connecting Cable*5,Antenna*6,Hexagon Screw pack*4,User's Manual*1 |
