Ahd Wireless Camera Monitor System

Product Description

720P Wireless Camera Monitor System

720P Wireless Camera Monitor System
Wireless Line of Sight Range Up to 300m
7" HD Screen Monitor Built-in 2.4GHz Wireless Receiver
Graphical OSD Menu Set Image Horizontal, Vertical, Mirror and Normal viewing, automatic cycle mode, night mode settings, reversing ruler settings, reversing the priority function is triggered
DC14~+87V(Td400mS) 5pulses Load Dump,600cd/m2 Brightness
720P Wireless Camera Built-in 2.4GHz Digital transmitter
IP69K Waterproof and 10G Vibration, IR LEDs for Night Vision
Built-in IR-CUT filter image colors more realistic
Free Operating Voltage: DC8~32V

720P Wireless Camera Monitor System
720P Wireless Receive Monitor(Model:MWHD-772S)
7" HD Screen Monitor with Removable Sun Visor
Built in 2 CH 2.4GHz Digital Wireless Receiver
Line of Sight Range Up to 300m
Operation Frequency:2400 ~ 2483.5MHz
Receiving Sensitivity:≤-86dBm(1MHZ QPSK MD300RE)
Overlapping Hopping Channel:80
Color System:PAL/NTSC
Display Resolution: 1024(H) X 600(V) dot
Wide view angle(CR>10):(up/ down): 50/70 (left/right): 70/70
Back-light : Single LED 600cd/m2 Brightness
Contrast ratio: 500:1
Operating temperature: -20ºC to +70ºC
Storage temperature: -30ºC to +80ºC
Free Operating Voltage: DC8~32V
External dimensions:L*W*T(207X149.5X85)mm(without mounting)
Weight Approx: 600g
720P Digital Wireless Waterproof IR Camera(MODEL:CWHD-161M-SFS*1)
Image Type: 1/3.7 inch Color CMOS
Built in 2.4GHz Digital wireless transmitter
Transmission Power:18dBm with Power control
Line of Sight Range:≤300M
Horizontal Resolution:720P
Effective pixel:PAL:1280(H)X960(V)
Usable Illumination : 0Lux ( Built in 6pcs IR LED's for Picture Support in the Dark)
Free viewing angle: 120°
IR-CUT: Automatic switch, day and night mode
Waterproof: IP69K
Shockproof: 10G
Free Operating Voltage: DC8-32 Volts
Dimensions: 103.5(W) x 89(H) x 67(D) mm
Weight : 450g
Accessorie
U- Support Bracket,Angle Adjustment Screw,Removable Sun Visor,Electrical Connecting Cable,Antenna*3,User's Manual

Ahd Wireless Camera Monitor System


Ahd Wireless Camera Monitor System
Ahd Wireless Camera Monitor System
Ahd Wireless Camera Monitor System
Ahd Wireless Camera Monitor System
Ahd Wireless Camera Monitor System
Ahd Wireless Camera Monitor System
