Farm Vehicle Rear View CCTV Safety Systems Multifunctional OSD Monitors
Product Description
Farm Vehicle Rear View CCTV Safety Systems Multifunctional OSD Monitors
Free Operating Voltage DC11-32 Volts Rear View Camera System
Rear View Cameras Installed on the Two-tier Bus top, the internal and the rear a different location
5" Digital Screen Rear View Monitor with Removable Sun Visor, On-Screen Menu for All Settings: Normal/Mirror view, Reversing Image Delay, Priority of Reverse Camera, Automatic switch ON (by reverse gear and or by direction lights), Built-in CDS Sensor for Illumination of the Control Knobs
Contact us if you need more details on Rear View System. We are ready to answer your questions on packaging, logistics, certification or any other aspects about Farm CCTV System、Vehicle Safety Systems. If these products fail to match your need, please contact us and we would like to provide relevant information.
Free Operating Voltage DC11-32 Volts Rear View Camera System
Rear View Cameras Installed on the Two-tier Bus top, the internal and the rear a different location
5" Digital Screen Rear View Monitor with Removable Sun Visor, On-Screen Menu for All Settings: Normal/Mirror view, Reversing Image Delay, Priority of Reverse Camera, Automatic switch ON (by reverse gear and or by direction lights), Built-in CDS Sensor for Illumination of the Control Knobs
| PRODUCT SPECIFICATION |
| Rear View CCTV Camera (MODEL:DF-8079*2) |
| Image Type: 1/3 Sony CCD |
| Horizontal Resolution:700TV Lines |
| Effective pixel:NTSCN : 976(H)×494(V) PAL:976(H)x582(V) |
| Usable Illumination : 0Lux ( Built in 18pcs IR LED's for Picture Support in the Dark) |
| Free viewing angle: 130° |
| Shockproof: 10G |
| Video Output:1.0Vp-p75Ω |
| Power supply:DC12V from Rear View Monitor |
| Dimensions: 69(W) x 43(H) x 38(D) mm (without mounting) |
| Weight:186g |
| 7 Inches Digital Screen TFT LCD Reversing Monitor (Model:SP-727N) |
| 7" Digital Screen TFT LCD Monitor with Removable Sun Visor |
| OSD MENU Separately Set Each Camera Trigger Priority |
| OSD MENU Separately Set Each Camera Reversing Image Delay Time 0-30" |
| OSD MENU Separately Set Each Camera Mirror/Normal image |
| Display Resolution: 800RGB(H) X 480(V) dot |
| Support Two Camera Inputs:1.0Vp-p75Ω |
| Wide view angle(CR>10):(up/ down): 45/65 (left/right): 65/65 |
| Brightness (cd/m2): 400 (Automatically Adjust Brightness to Display by According Environment) |
| Contrast ratio: 500:1 |
| Back-light: Single LED |
| Operating temperature: -20ºC to +70ºC |
| Storage temperature: -30ºC to +80ºC |
| Power suply: DC8~32V |
| External dimensions: (L x W x T) (185X122X28)mm without mounting Sun Visor |
| Weight Approx: 239g |
| Product Accessories |
| Monitor bracket, 15m cable, Electrical connecting cable, Auto cigarette lighter,Remote Control, User's Guide |
Contact us if you need more details on Rear View System. We are ready to answer your questions on packaging, logistics, certification or any other aspects about Farm CCTV System、Vehicle Safety Systems. If these products fail to match your need, please contact us and we would like to provide relevant information. Product Categories : HD Wired Rearview Camera System > Others HD Wired Rearview Camera System
