Port Crane Quad Wired Reversing Backup IR Camera System

Port Crane Quad Wired Reversing Backup IR Camera System
Port Crane Quad Monitor Camera System Eliminate Blind Spots on Port Harbor Crane, Tower Crane, Container Stacker Crane Equipment
9" Digital Screen Quad Monitor is Able to Show 1, 2, 3 or 4 Views at one Time, Automatically Adjust Brightness to Display and Button by According Environment, OSD MENU Separately Set Each Camera Mirror/Normal image, Image Delay and Priority, 400cd/m2 Brightness, Load Dump DC14+87V(Td400mS) 5pulses
Aluminum Shell Camera 700TV Lines IP69K Waterproof and 10G Vibration, Ultra Bright Wavelength 850nm IR LEDs for Night Vision
System Free Operating Voltage DC11~32V

Specification

9 inches Digital Screen TFT LCD Quad Monitor(Model:SP-937)

9"Digital Screen TFT LCD Quad Monitor with Sun Visor

Single View/Split View/Three View/Quad imag View Selectable Totally 8 different view modes. Each camera can be full displayed when it is triggered.

Blue Backlight Keypad will Help Drivers to See and Operate Acurately at Night or Low Light Situation

OSD MENU Separately Set Each Camera Trigger Priority

OSD MENU Separately Set Each Camera Mirror/Normal image

Application USA Techwell Automotive Digital Video Processor

1 Cable Solution System Make It Easy For Users To Install and Use The Device In Any Places

4 Color Trigger Wires (reversing/ turn left/ turn right/ front) are used for Automatically Showing Image full Screen when it is Activated

Color System:PAL/NTSC (AUTO)

Display Resolution: 2400(H) X 480(V) dot

Support Four Camera Inputs:1.0Vp-p75Ω

Contrast ratio: 500:1

Back-light:Single LED

Operating temperature: -20ºC to +70ºC

Storage temperature: -30ºC to +80ºC

Load Dump: DC14+87V(Td400mS) 5pulses

Free Operating Voltage: DC11-32V (System Power Max 20W)

External dimensions::(L x W x T) (234 x158 x 81mm) with mounting Sun Visor

Weight Approx: 479g

Aluminum Shell Waterproof IR Side CCD Camera(MODEL:DF-8079*4)

Image Type: 1/3 inch Color CCD

Horizontal Resolution:700TV Lines

Effective pixel:NTSC:976(H)×494(V) PAL:976(H)x582(V)

Usable Illumination : 0Lux( Built in 18pcs IR LED's for Picture Support in the Dark)

Free viewing angle: 130°

Waterproof: IP69k

Shockproof: 10G

Video Output:1.0Vp-p75Ω

Power supply:DC12V (from Reversing Monitor)

Dimensions: 69(W) x 43(H) x 38(D) mm (without mounting)

Product Accessories

U- Support Bracket,Angle Adjustment Screw,Removable Sun Visor,Electrical Connecting Cable,15m cable*4, Auto cigarette lighter,User's Manual



Contact us if you need more details on Reversing Camera Kits. We are ready to answer your questions on packaging, logistics, certification or any other aspects about Backup Camera Kits、Wired Camera Kits. If these products fail to match your need, please contact us and we would like to provide relevant information.
